Модуль для редактирования прошивок блоков управления Denso бензиновых турбированных автомобилей Toyota Yaris GR 1.6 Turbo с двигателем G16E-GTS.
Для редактирования доступны файлы из MCU1 c номером ПО 8A230-52XXX размером 4 Мб.
Доступны следующие карты:
Air control: Effeciency in additional mode, Maximal mass air flow
Boost control: limitation: Boost correction factor, Maximal boost pressure absolute, Torque clamp boost limiter, Boost limitation absolute, Boost limitation by torque, Boost limitation relative, Maximal boost relative
Boost control: wastegate: Target wastegate duty, Wastegate duty in additional speed
Camshaft Control: Intake Camshaft, Intake camshaft correction, Intake camshaft correction factor
Engine speed limit: Engine speed limitation
Fuel Pressure: Target fuel pressure, Maximum fuel pressure
Fuelling Direct Injection: Injection I angle in additional mode, Injection II angle in additional mode
Ignition Optimum: Spark advance optimal
Sensors scaling: Mass air flow sensor scaling
Spark advance: Ignition efficiency, Minimal spark advance, Spark advance in additional mode, Spark advance main, Spark advance retardation on camshaft, Spark advance warmup correction
Throttle control: Primary throttle efficiency in additional gear, Primary throttle efficiency 1 [Normal mode], Primary throttle efficiency 1 [Sport mode], Primary throttle efficiency 2 [Normal mode], Primary throttle efficiency 2 [Sport mode], Primary throttle efficiency base, Primary thrttle efficiency [gear 2], Throttle efficiency idle, Throttle position base
Throttle: direct control: Throttle control limit in additional gear [Normal], Throttle control limit in additional gear [Sport], Throttle direct control limit [1st GEAR], Throttle direct control limit [1st GEAR] AWD High, Throttle direct control limit [1st GEAR] AWD Low, Throttle direct control limit [Reverse GEAR], Throttle direct control limit
Torque model: Calculated torque from load, Engine speed by throttle position, Maximal engine torque, Torque Limiter, Torque limiter by temperature, Maximal torque
Vehicle speed limit: Vehicle speed limiter (если найден)
